Vibrating feeder

jintai30Vibrating feeder can feed block or granule materials from the material storage to charging device evenly and continuously. It can realize even feeding for crushers in sandstone production line and make rough screening for materials. Widely applied in combined operation of crushing and screening in the industries like metallurgy, mine, mine ion, building materials, chemicals, etc.

Characteristics of Vibrating Feeder:
Stable vibration, reliable operation and long service life; the excitation force and materials quantity moving in the feeder can be adjusted conveniently and easily; the vibrating motor, as the excitation source, has low noise, small power consumption, good adjusting performance and without material splash. Simple structure, reliable running, convenient installation, light weight, small size, easy maintenance, and the enclosed type can prevent dust pollution.

Zhengzhou Jintai Mining Machinery Limited is specialized in manufacturing mineral processing machinery and providing mineral processing technology for concentration plants. Our company is known for producing Ball Mill, Grate Ball Mill, Crusher, Classifier, dryer, mixer,Magnetic Separator, CTB series of Magnetic Separator, Flotation Machine, SF Flotation Machine, XJ Flotation Machine, Centrifugal Separator ,Vibrating feeder and so on. We are a professional Vibrating feeder supplier and we provide Vibrating feeder price, Vibrating feeder working principle for you. If you have any need, please contact us, we will provide you our best service .

0086-0371-68713618    0086-0371-68723618
13383828296


Technical parameters of vibrating feeder :

Model Max.
feeding
(mm) Pocessing
capacity
(t/h) Motor
power
(kw) Obliquity
of material trough
(o) Total
weight
(kg) Trough
size
(mm) Dimensions
(L*W*H)
(mm)
GZD-650*2300 300 80 1.5*2 10 2798 650*2300 2300*1360*780
GZD-750*2500 350 100 1.5*2 10 3260 750*2500 2500*1460*780
GZD-850*3000 400 120 3*2 10 3607 850*3000 3110*1800*1600
GZD-1000*3600 500 150 5.5*2 5 3895 1000*3600 3850*1950*1630
GZD-1100*4200 580 240 5.5*2 5 4170 1100*4200 4400*2050*1660
GZD-1100*4900 580 280 7.5*2 5 4520 4900*1100 5200*2050*1700
GZD-1300*4900 650 450 11*2 5 5200 4900*1300 5200*2350*1750
ZSW-380*95 500 96-160 11 0 4082 3800*960 3920*1640*1320
ZSW-490*110 630 120-280 15 0 5352 4900*1100 4980*1830*1320
ZSW-600*130 750 400-560 22 0 7800 6000*1300 6082*2580*2083
